Category: HD-AVS Kits
SKU: PantherView4-4B-1080-Kit
$499.94
Add To Cart

Key Features

Amitriptyline for Back Pain

amitriptyline for nerve pain

How to Take Amoxicillin

how to take amoxicillin poisel.cz buy amoxicillin over the counter

Amitriptyline for Anxiety

buy antidepressants visa read here buy antidepressants visa

clomid birmingham

buy clomid tablets

clomid uk buy online

clomid london click here clomid manchester

order naltrexone pills

naltrexone for alcoholism blog.zycon.com buy naltrexone

buy antidepressants visa

amitriptyline 10mg singlvkuchyni.cz buy amitriptyline london
  • 4 Ch 4 Megapixel HD-AVS DVR
  • H.265 / H.264 Dual-stream video compression
  • Support HDCVI/CVBS video inputs
  • Max 6 ch IP camera inputs, up to 5MP per ch
  • Max 24Mbps Incoming Bandwidth
  • HDMI output up to 4K(3840x2160) resolution
  • Smart Search and Intelligent Video System
  • 2 SATA Ports
  • Supports up to 6TB capacity for each disk
  • Includes 1 TB Drive, 4 HD2-TD20A Dome Cams

Specifications
System
Main Processor Embedded Processor
Operating System Embedded LINUX
Display
Interface 1 HDMI(up to 3840x2160), 1 VGA
Resolution 3840x2160,1920×1080, 1280×1024, 1280×720, 1024×768
Multi-screen Display 1/4/6
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Camera Blank
Alarm input N/A
Relay Output N/A
Tracking Trigger Event N/A
Video Detection and Alarm
Trigger Events Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Camera Blank
Alarm Input Alarm input N/A
Relay Output Relay Output N/A
Tracking Trigger Event Tracking Trigger Event N/A
Playback and Backup
Playback 1/4
Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode USB Device/Network
Storage
Internal HDD 2 SATA Ports, up to 6TB capacity for each disk
HDD Mode Single
eSATA N/A
Auxiliary Interface
Front Cover N/A
USB 2 USB Ports (1 USB 2.0 , 1 USB 3.0)
RS232 N/A
RS485 1 Port, for PTZ Control
Third-party Support
Third-party Support ClearView, IC Realtime, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Audio and Video
HDCVI Camera Input 4 Channel
IP Camera Input 4+2 Channel, each channel up to 5MP
Audio In/Out 1/1
Two-way Talk 1 Channel Input, 1 Channel Output, RCA
Recording
Compression H.265 / H.264
Resolution 4MP,1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
Record Rate Main stream: 4MP(1~15fps) 1080P/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps) Sub steram:D1/CIF/QCIF(1~25/30fps)
Bit Rate 32Kbps ~ 6144Kbps Per Channel
Record Mode Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Network
Interface 1 RJ-45 Port (1000M)
Network Function HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.)
Max. User Access 128 users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 2.4.1, CGI Conformant
Electrical
Power Supply DC12V/4A
Power Consumption <15W (Without HDD)
Environmental
Operating Conditions +14°F ~ +131°F, 86 ~ 106kpa 0°
Storage Conditions +32°F ~ +122°F, 0 ~ 90% RH
Construction
Dimensions 1U, 14.8" x 11.2" x 2.2"
Net Weight 5.2 lb (without HDD)
Gross Weight 7.05 lb
Installation Desktop installation
Certifcations
Certifications UL: Coming Soon

What's Included

Downloads
iClearView iPad / iPhone AppLinkDownload
iClearView Android AppLinkDownload
ClearView SmartPSS Remote Client Software (Windows Version 1.13.0)Download
ClearView SmartPSS Remote Client Software (Mac Version 1.10.1)Download
ClearView Player V3.34.16 (Windows Version)Download
Drivers for Universal 232 Protocol SupportDownload
Drivers for Control 4 Home Automation SupportDownload
Drivers for RTI Home Automation SupportDownload
IP Auto Search Device Finder for IP Cams (Windows Version)Download
DDNS Setup InstructionsLinkDownload
ActiveX Clear Cache FixDownload
MPTZ-2 Mac Web PluginDownload
HD-AVS DVR Series Quick Start Guide V2.0.0PDFDownload
HD-AVS DVR Series Users Manual V1.1.0PDFDownload
IP-007 Network Camera Operations ManualPDFDownload
IP-007 WebpluginDownload
Panther 16HP Tri User ManualPDFDownload
Panther Kit Installation GuidePDFDownload
Panther-32-Tri Player Users GuidePDFDownload
Panther-32-Tri Users Manual V1.7.0PDFDownload
PantherView5-16-08D Quick Start GuidePDFDownload
