| Main Processor: |
Embedded Processor |
| Operating System: |
Embedded LINUX |
| Display Interface: |
1 HDMI(up to 3840x2160), 1 VGA |
| Resolution: |
3840x2160,1920×1080, 1280×1024, 1280×720, 1024×768 |
| Multi-screen Display: |
1/4/6/8/9/16 |
| OSD: |
Title, Time, Video loss, Camera lock, Motion detection, Recording |
| Trigger Events: |
Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection: |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Camera Blank |
| Trigger Events: |
Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection: |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Camera Blank |
| Playback: |
1/4/9 |
| Search Mode: |
Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function: |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode: |
USB Device/Network |
| Internal HDD: |
2 SATA Ports, up to 6TB capacity for each disk |
| HDD Mode: |
Single |
| USB: |
2 USB Ports (1 USB 2.0 , 1 USB 3.0) |
| Third-party Support: |
ClearView, IC Realtime, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Audio In/Out: |
1/1 |
| Two-way Talk: |
1 Channel Input, 1 Channel Output, RCA |
| HDCVI Camera Input: |
8 Channel |
| IP Camera Input: |
8+4 Channel, each channel up to 5MP |
| Recording Compression: |
H.265 / H.264 |
| Resolution: |
4MP, 1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Record Rate: |
Main stream: 4MP(1~15fps) 1080P/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps) Sub steram:D1/CIF/QCIF(1~25/30fps) |
| Bit Rate: |
32Kbps ~ 6144Kbps Per Channel |
| RS485: |
1 Port, for PTZ Control |
| Record Mode: |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval: |
1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Network Interface: |
1 RJ-45 Port (1000M) |
| Network Function: |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support IP camera, DVR, NVS, etc.) |
| Max. User Access: |
128 users |
| Smart Phone: |
iPhone, iPad, Android |
| Interoperability: |
ONVIF 2.4.1, CGI Conformant |
| Power Supply: |
DC12V/4A |
| Power Consumption: |
<15W (Without HDD) |
| Operating Conditions: |
+14°F ~ +131°F, 86 ~ 106kpa 0° |
| Storage Conditions: |
+32°F ~ +122°F, 0 ~ 90% RH |
| Dimensions: |
1U, 14.8” x 11.2” x 2.2” |
| Net Weight: |
5.2 lb (without HDD) |
| Gross Weight: |
7.05 lb |
